Unlock the full potential of your CSL DD.
Designed specifically for the CSL DD, the Boost Kit 180 provides more power to the direct-drive wheel base to enable the highest performance. This provides much stronger feedback, and as a result, you’ll feel the subtle cues more clearly too.
By raising the standard peak torque of 5 Nm to 8 Nm, the Boost Kit 180 transforms the force feedback of the CSL DD due to its significantly wider dynamic range.
By using the Boost Kit 180 instead of the standard power supply, the wheel base unlocks its full performance automatically. No other setup required.
CSL DD. The new standard.
FANATEC® Direct-Drive technology comes to the CSL Series. From subtle sidewall flex to powerful self-aligning torque, you’ll feel everything with a heightened sense of realism. Exceptionally crisp and dynamic force feedback sensations await.
When the steering wheel is directly mounted to the motor shaft, there’s no belt or gear drive to dilute the force feedback effects. The clear choice of all professional drivers and enthusiast sim racers is now available to a broader audience.
The efficiency of the CSL DD motor technology means dynamic force-feedback performance is contained in a small footprint. This is also the first industrial motor to feature a carbon fibre composite motor shaft, which increases responsiveness and acceleration significantly due to low rotational masses.
Boost Kit 180:
- Larger, 180W power supply unlocks full performance of CSL DD (standard power supply is 90W)
- Designed and tested specifically for the CSL DD
- Improves dynamic range (from 5 Nm to 8 Nm peak torque)
- Direct-Drive system delivers instant, detailed force feedback
- Linear, consistent performance (8 Nm peak torque with Boost Kit 180)
- Patented, exclusive FluxBarrier™ technology optimises motor efficiency and smoothness
- Full Fanatec SDK support ensures game compatibility out of the box for all major racing games
- Standard Tuning Menu allows beginners to get started quickly without having to worry about settings
- Advanced Tuning Menu allows enthusiasts to fine-tune the force feedback characteristics to suit their driving preferences
- High-resolution (contactless) Hall-position-sensor, same as Podium Series
- Steering axis made from carbon fibre-enhanced composite
- Fanless: wheel base housing is made from aluminium (passive heat sink, core structural component) with composite end caps.
- Wireless-QR technology (slip ring system, life-tested 24/7 for thousands of hours) means no mechanical rotation limiter, provides cable-free delivery of power and data to steering wheels.
- Automotive-grade quick release, exchangeable
- T-nut rail system on sides and bottom for easily adjustable hard-mounting
- Temporary mounting possible with optional table clamp (not included), supports 5 to 60 mm table thickness
- Power supply
- USB-C to PC / console
- Fanatec DataPort-C
- Shifter 1
- Shifter 2 (Sequential only)
- Front-mounted threaded inserts for Fanatec accessories (e.g. ClubSport Static Shifter Paddles, available separately). Not intended for front-mounting the wheel base to a sim racing chassis/cockpit.
The CSL DD is compatible with:
- Fanatec Podium Steering Wheels
- Fanatec ClubSport Steering Wheels
- Fanatec CSL Steering Wheels
- All Fanatec Pedals (adapter cables might be required on pedals without RJ12 connection)
- Fanatec ClubSport Shifters (including ClubSport Static Shifter Paddles)
- Fanatec ClubSport Handbrake V1 and V1.5
- Fanatec RennSport Cockpits
- ClubSport Table Clamp V2
- CSL DD Table Clamp
- Boost Kit 180
- Podium Mounting Brackets (the CSL DD includes M6 T-nuts for side-mounting; the Podium Mounting Brackets require the use of M6 bolts and washers).
- PC: This wheel base is compatible with PC when combined with a Fanatec Steering Wheel. Check the individual Steering Wheel product pages for Wheel Base compatibility.
- Xbox®: This wheel base becomes compatible with Xbox One® and Xbox Series X|S when used with any Fanatec Xbox-licensed steering wheel.
- PlayStation®: This product is not compatible with any PlayStation® console and cannot be upgraded to achieve compatibility.
- Not suitable for children. A Direct Drive Wheel Base is not a toy! The fast movements of the steering wheel and strong torque can be dangerous. Please read the safety instructions.
- In order to enable features such as Steering Wheel LEDs in some titles, it may be necessary to switch the CSL DD to Compatibility Mode. This can also help with titles not working in standard PC mode. Check the Quick Guide for details.
- The CSL DD was developed and tested with the Boost Kit 180 in mind. The durability is not affected by the higher power.
- The electronics of the Wheel Bases recognise whether a Boost Kit 180 is connected and automatically call up the additional power.
- Due to the addition of the Boost Kit 180 (180W power supply), the standard 90W power supply is not included.
- This product has been tested with the Wheel Base and complies with all regional electronic safety standards. Use of any other power supply will void the Wheel Base warranty and may cause damage.
- CSL DD Wheel Base
- BOOST KIT 180
See Fanatec official website for further info.
